Pre Engineered Building (PEB) Manufacturer in Delhi NCR
- Structure: Clear-span structural steel warehouse sheds up to 60+ meters without center columns
- Fabrication: Built-up welded I-section columns, tapered rafters, and cold-formed Z/C purlins
- Speed: 50% faster construction than traditional civil RCC buildings
- Cladding: High-tensile pre-painted Galvalume roof and wall profile sheets
dial4web
Reliance Logistics
Amazon Fulfilment
Flipkart Supply Chain
Blinkit Dark Stores
BigBasket Regional DC
Mother Dairy Cold Depots
Haldiram Foods
Havells India Supply
Relaxo Footwear Logistics
Delhivery Mega Hub
Dabur India Distribution
Product Overview & Engineering
What is a Pre Engineered Building (PEB)? A Pre Engineered Building (PEB) is a modern structural steel building concept where primary framing (tapered I-section columns and rafters), secondary framing (galvanized Z and C purlins), and pre-painted Galvalume roof/wall cladding are custom-designed and 100% factory-fabricated at our Mundka manufacturing plant. All components are transported to the project site pre-cut, pre-punched, and pre-welded for rapid bolted assembly.
Where is it Used? The building standard for modern industrial parks across Manesar, Dharuhera, Neemrana, Ghaziabad, and Sonipat for warehouses, manufacturing plants, and logistics facilities.
Key Benefits & Advantages:
• 50% faster construction compared to conventional masonry and RCC buildings.
• Wide clear-spans up to 60+ meters without internal columns, maximizing unobstructed storage space.
• High-tensile Galvalume roofing provides 25+ years of corrosion resistance against harsh weather.
• Engineered strictly to Indian Building Codes for wind speed resistance (up to 47 m/s) and seismic zone safety.
How Vaishno Storage Solution Manufactures This System: At our Mundka plant, high-strength IS 2062 Grade E350 steel plates are profile-cut using automated CNC oxy-fuel cutters and submerged-arc welded (SAW) into tapered I-beam rafters and columns. Secondary purlins are cold roll-formed from galvanized steel coils. All steel components are blast-cleaned, primed with zinc chromate rust primer, and top-coated before shipment.
How We Install on Site: Our structural erection crew mounts columns onto pre-cast concrete foundation anchor bolts using mobile cranes, ties rafters into rigid portal frames, fastens roof and wall purlins with high-tensile Grade 8.8 bolts, and fastens Galvalume profile sheets with EPDM self-drilling screws.
PEB Building Manufacturers in Delhi
Vaishno Storage Solution is an established peb building manufacturer in Delhi, operating a full-scale fabrication facility at Mundka Udyog Nagar, West Delhi. We produce high-strength industrial peb building utilizing certified prime-grade hot-rolled and cold-rolled steel (IS 2062 Grade E250 / E350) sourced directly from reputed primary mills including Tata Steel, JSW, and SAIL. Each structural upright, load beam, and shelf panel is crafted through computer-controlled multi-station cold roll-forming and CNC perforation lines, ensuring strict 50 mm modular adjustability and millimeter-accurate tolerances. With our complete in-house pre-treatment (7-tank hot chemical phosphating) and electrostatic thermosetting powder coating line, we eliminate third-party processing delays and pass direct factory pricing to end-user enterprises across Delhi and NCR.
PEB Building Suppliers in Delhi NCR
As leading peb building suppliers in Delhi NCR, Vaishno Storage Solution delivers turnkey storage implementations across key industrial clusters including Mundka, Mayapuri, Okhla, Bawana, Narela, Gurugram, Manesar, Noida, Greater Noida, Ghaziabad, Sahibabad, Faridabad, Sonipat, Kundli, and Bahadurgarh. We maintain active ready stock of standard upright frames, horizontal step beams, panel shelves, and slotted angle sections to enable emergency 24- to 48-hour dispatches. Our factory-trained erection teams arrive equipped with mechanical floor anchor systems, torque-controlled fasteners, and laser leveling tools to complete defect-free on-site installation with zero disruption to warehouse throughput.
PEB Building Wholesalers & Bulk Dealers in Delhi
For 3PL logistics operators, e-commerce fulfillment hubs, commercial infrastructure contractors, and industrial dealers, Vaishno Storage Solution acts as a dependable peb building wholesaler in Delhi. We offer tier-based bulk commercial discounts based on total steel tonnage and running bay volume, delivering transparent savings of 15% to 25% compared to intermediary retail traders and local hardware vendors. Every commercial order includes a detailed Bill of Quantities (BOQ), verified Mill Test Certificates (MTC), structural deflection calculations, and complimentary 2D warehouse CAD layout engineering.
PEB Building B2B Price Benchmark & Quality Comparison
| Parameter / Feature | Vaishno Storage Solution (Factory Direct) | Open Market / Trader Reseller |
|---|---|---|
| Indicative Price | ₹220 – ₹550 per square foot | +18% to +30% higher (Trader margin added) |
| Structural Steel Quality | Prime IS 2062 Grade E250 / E350 (Tata / JSW / SAIL tested) | Commercial grade / re-rolled secondary HR steel |
| Anti-Corrosion Surface Finish | 7-Tank hot phosphating + 80µ electrostatic epoxy powder coating | Manual air-dry synthetic enamel spray (prone to flaking) |
| CAD Layout & Load Calculations | Free 2D/3D warehouse CAD floor plan with certified UDL calculations | No engineering drawings; generic rough estimations |
| Turnkey Erection & Anchoring | Factory-certified structural riggers with mechanical floor anchor bolts | Third-party unvetted day labor or customer self-assembly |
| Standard Dispatch Time | 24–48 hours for standard sizes; 5–8 days for custom orders | Uncertain lead times dependent on third-party suppliers |
| Parameter | Specification Details |
|---|---|
| Primary Structural Framing | High-strength built-up I-sections (IS 2062 Grade E350 steel) with tapered rafters and columns |
| Secondary Framing | Cold-formed galvanized Z and C purlins (275 g/m² zinc coating, 1.8 to 2.5 mm steel) |
| Roof & Wall Cladding | 0.50 mm / 0.55 mm TCT Pre-Painted Galvalume (PPGL) high-tensile steel profile sheets (550 MPa) |
| Clear Spans | 15 meters up to 60+ meters unobstructed clear spans |
| Eave Heights | 6 meters up to 15 meters clear warehouse height |
| Wind & Seismic Design | Designed strictly to IS 875 (Part 3) Wind Codes & IS 1893 Seismic Standards |
| Accessories Included | Ridge ventilators, polycarbonate daylight skylight sheets, turbo ventilators, gutters & downspouts |
| Foundation Fastening | Heavy foundation anchor bolts (Grade 8.8 / 10.9) cast directly into RCC column pedestals |
Available Sizes & Variants
| Model / Size | Load Capacity | Recommended Application |
|---|---|---|
| Small Industrial Factory Shed (5,000–15,000 sq ft) | Clear-span manufacturing shed | Machining units, light fabrication & assembly workshops |
| Large Logistics Warehouse (20,000–100,000+ sq ft) | High-cube warehouse with 12m height | 3PL distribution centers, e-commerce hubs & cold storage facilities |
| Crane-Ready Industrial Shed | With 5T–20T EOT gantry crane brackets | Heavy engineering, steel processing & machinery fabrication |
Recommended Applications & Warehouse Environments
Industrial warehouse sheds, factory manufacturing plants, 3PL logistics parks, cold storage outer envelopes, agro-processing godowns, sports complexes.
How We Manufacture & Install PEB Building
Manufacturing at Mundka Plant
-
1
Prime Steel Profiling High tensile IS 2062 Grade E250 / E350 steel slitted and inspected for yield strength consistency.
-
2
CNC Cold Roll-Forming Automated multi-stand cold roll forming lines produce continuous profiles with precise 50 mm pitch perforations.
-
3
7-Tank Chemical Pre-Treatment Hot alkaline degreasing, derusting, water rinses, and zinc phosphating create superior powder bonding and rust resistance.
-
4
Electrostatic Powder Coating Thermosetting epoxy-polyester powder applied at 70–80 microns and baked at 200°C for industrial scratch resistance.
On-Site Turnkey Installation
-
1
Floor Slab & Laser Plumb Check Optical laser levels assess warehouse concrete floor flatness, expansion joints, and plumb lines prior to erection.
-
2
Heavy Duty Chemical / Mechanical Anchoring Base plates secured with M12/M16 high-grade anchor bolts embedded into the industrial concrete floor slab.
-
3
Safety Locks & Cross-Bracing Spring-loaded safety pins prevent accidental beam dislodgement from forklift contact, supplemented by horizontal and diagonal cross-ties.
-
4
Load Testing & Signage Sign-Off Rigorous deflection checks under live weight followed by affixing certified UDL load capacity safety signboards.
How PEB Building Compares
Factors Determining PEB Building Cost
Request Factory Quote
Receive a complete BOQ & 2D CAD layout within 24 hours.
PEB Building FAQs
Common questions regarding technical capacity, fabrication lead time, and installation.
